Lensagon TC5M-10-150I
High Res Object Side Telecentric Lens for 2/3 inch sensor, Magnification: 1.00x, WD 150.00mm, F# 7.50, NA 0.07, DOF 210.00um, Opt.Dist. 0.03
Product Description
The Object Side Telecentric Lens TC5M-10-150I is suitable for sensors up to 5.00 megapixel.
| Magnification | 1.00 x |
|---|---|
| Working Distance (WD) | 150.00 mm |
| Depth of Field (DOF) | 210.00 μm @ 14.00 μm |
| Resolution (Object Side) | 5.10 μm |
| Image Format (max.) | 2/3 inch |
| Megapixel (max.) | 5.00 MP |
| Working F-Number | 7.50 |
| Numerical Aperture (NA) | 0.07 |
| Field of View (FOV) | 8.45 mm x 7.1 mm |
| Telecentric Type | Object Side |
| Telecentricity | 0.03 ° |
| Optical Distortion (max.) | 0.03 % |
| Mount | C-Mount * |
* Other mounts are available on request.
