Lensagon TC5M-05-110

Lensagon TC5M-05-110

Super High Res Object Side Telecentric Lens for 2/3 inch sensor, Magnification: 0.5x, WD 110mm, F# 5.38, NA 0.0465, DOF 861um, Opt.Dist. 0.02

 Compare
SKU: 01014 Category:

Product Description

The Object Side Telecentric Lens TC5M-05-110 is suitable for sensors up to 5 megapixel and with an image format of 2/3 inch.

Magnification 0.5
Mount C-Mount
Aperture 5.38
Working Distance (WD) 110 mm
Depth of Field (DOF) 861 μm
Resolution (Object Side) 7.2 μm
Numerical Aperture (NA) 0.0465
Image Format (max.) 2/3 inch
Megapixel 5
Field of View (FOV) 16.9mm x 14.2mm
Lens Type Object Side
Telecentricity 0.02
Optical Distortion (max.) 0.02 %
Special Feature Super High Res
pdf

Additional Information

Technical Drawing:

Drawing
