Lensagon MF8M-063-310I

Lensagon MF8M-063-310I

Macro Lens for 8M (23mm) sensor, Magnification: 0.63x, WD 310mm, F# 6.5, NA 0.0485, DOF 720um, Opt.Dist. 0.08

 Compare
SKU: 10965 Category:

Product Description

The Macro Lens MF8M-063-310I is suitable for sensors up to 8 megapixel and with an image format of 8M (23mm).

Magnification 0.63 x
Mount F-Mount
Working F-Number 6.5
Working Distance (WD) 310 mm
Depth of Field (DOF) 720 μm
Resolution (Object Side) 6.9 μm
Numerical Aperture (NA) 0.0485
Image Format (max.) 8M (23mm)
Megapixel (max.) 8 MP
Field of View (FOV) 28.76mm x 21.57mm@8M CCD
Telecentric Type Macro
Optical Distortion (max.) 0.08 %
pdf

Additional Information

Technical Drawing:

Drawing
