Lensagon BM3518S125NDV2C
0.00 Megapixel S-Mount lens for 1/2.5 inch sensors, F1.80, f=3.50mm
Product Description
The S-Mount lens Lensagon BM3518S125NDV2C is suitable for sensors below 1 megapixel with an image format of 1/2.5 inch. It is characterized by a particularly high light intensity.
| Mount | S-Mount |
|---|---|
| Sensor | 1/2.5 inch |
| Focal Length | 3.50 mm |
| max. Focal Length | 0.00 |
| Aperture (f#) | 1.80 |
| MOD | 0.20 m |
| Back Focal Length | 5.99 |
| Angle of View (D) | 90.00° / H: 84.00° / V: 68.00° |
| Megapixel (max.) | 0.00 MP |
| IR Correction | No |
| IR Cut Filter | Yes |
| Optical Distortion | -1.50 % |
| TV Distortion | 0.00 |
| Image Circle | 7.20 mm |
| Weight | 13.70 g |
| Iris | fixed |
| Focus | fixed |
| Chief ray angle | 9.40 ° |
| Typ | Standard |
