Lensagon B5M2524

Lensagon B5M2524

5 Megapixel S-Mount lens for 1/2.5 inch sensors, F2.4, f=2.5mm

 Compare
SKU: 09927 Category:

Product Description

The S-Mount lens Lensagon B5M2524 is suitable for common sensors up to 5 megapixel with an image format of 1/2.5 inch.

Mount S-Mount
Sensor 1/2.5 inch
Focal Length 2.5 mm
Aperture (f#) 2.4
MOD 0.1 m
Back Focal Length 4.7
Angle of View (D) 166°
Megapixel 5 MP
IR Cut Filter No
Optical Distortion -83 %
Image Circle 7.4 mm
Weight 12 g
Iris fixed
Focus fixed
Typ Standard
pdf

Additional Information

Technical Drawing:

Drawing
