Lensagon BF10M14522S118

Lensagon BF10M14522S118

10 Megapixel Fisheye S-Mount lens for 1/1.8 inch sensors, F2.2, f=1.45mm

 Compare
SKU: 10814 Category:

Product Description

The S-Mount lens Lensagon BF10M14522S118 is suitable for current sensors up to 10 megapixel with an image format of 1/1.8 inch.

Mount S-Mount
Sensor 1/1.8 inch
Focal Length 1.45 mm
Aperture (f#) 2.2
MOD 0.1 m
Back Focal Length 4.62
Angle of View (D) 190°
Megapixel 10 MP
IR Correction Yes
IR Cut Filter No
Optical Distortion -4.75 %
Image Circle 4.6 mm
Iris fixed
Focus fixed
Typ Fisheye
pdf

Additional Information

Technical Drawing:

Drawing
