Lensagon B6M81756S118FTC
6.0 Megapixel S-Mount lens for 1/1.8 inch sensors, F5.60, f=8.17mm, MOD 0.100m
Product Description
The S-Mount lens Lensagon B6M81756S118FTC is suitable for current sensors up to 6.0 megapixel with an image format of 1/1.8 inch.
| Mount | S-Mount |
| Sensor | 1/1.8 inch |
| Focal Length | 8.17 mm |
| Aperture (f#) | 5.60 |
| MOD | 0.100 m |
| Angle of View (D) | 57.50° / H: 47.20° / V: 36.20° |
| Megapixel (max.) | 6.0 MP |
| IR Cut Filter | Yes |
| Optical Distortion | -1.54 % |
| Image Circle | 9.40 mm |
| Iris | fixed |
| Focus | fixed |
| Chief ray angle | 17.25 ° |
