Lensagon B10M5428S123NDC
10.0 Megapixel S-Mount lens for 1/2.3 inch sensors, F2.80, f=5.40mm, MOD 0.500m
Product Description
The S-Mount lens Lensagon B10M5428S123NDC is suitable for current sensors up to 10.0 megapixel with an image format of 1/2.3 inch.
| Mount | S-Mount |
| Sensor | 1/2.3 inch |
| Focal Length | 5.40 mm |
| Aperture (f#) | 2.80 |
| MOD | 0.500 m |
| Back Focal Length | 6.68 |
| Angle of View (D) | 72.20° / H: 61° / V: 47.50° |
| Megapixel (max.) | 10.0 MP |
| IR Correction | No |
| IR Cut Filter | Yes |
| Optical Distortion | -1.70 % |
| Image Circle | 7.90 mm |
| Weight | 7 g |
| Iris | fixed |
| Focus | fixed |
| Chief ray angle | 13.20 ° |
