Lensagon TF15M-07-180I
Super High Res Object Side Telecentric Lens for 25mm (diagonal) sensor, Magnification: 0.7x, WD 180mm, F# 6, NA 0.0588, DOF 538um, Opt.Dist. 0.03
Product Description
The Object Side Telecentric Lens TF15M-07-180I is suitable for sensors up to 15 megapixel and with an image format of 25mm (diagonal).
| Magnification | 0.70 x |
|---|---|
| Working Distance (WD) | 180.00 mm |
| Depth of Field (DOF) | 538.00 μm @ 22.00 μm |
| Resolution (Object Side) | 5.70 μm |
| Image Format (max.) | 25mm (diagonal) |
| Megapixel (max.) | 15.00 MP |
| Working F-Number | 6.00 |
| Numerical Aperture (NA) | 0.0588 |
| Field of View (FOV) | 25.1mm x 25.1mm |
| Telecentric Type | Object Side |
| Telecentricity | 0.04 ° |
| Optical Distortion (max.) | 0.03 % |
| Mount | F-Mount * |
* Other mounts are available on request.
