Lensagon TCST-40-65

Standard Object Side Telecentric Lens for 1/2 inch sensor, Magnification: 4x, WD 65mm, F# 26.3, NA 0.076, DOF 132um, Opt.Dist. 0.03

 Compare
SKU: 10008 Category:

Product Description

The Object Side Telecentric Lens TCST-40-65 is suitable for sensors with an image format of 1/2 inch.

Magnification 4 x
Working Distance (WD) 65 mm
Depth of Field (DOF) 132 μm @ 40 μm
Resolution (Object Side) 4.4 μm
Image Format (max.) 1/2 inch
Working F-Number 26.3
Numerical Aperture (NA) 0.076
Field of View (FOV) 1.6mm x 1.2mm @ 1/2″
Telecentric Type Object Side
Telecentricity 0.04 °
Optical Distortion (max.) 0.03 %
Mount C-Mount *

* Other mounts are available on request.
