Lensagon TCST-20-40

Lensagon TCST-20-40

Standard Object Side Telecentric Lens for 1/2 inch sensor, Magnification: 2x, WD 40mm, F# 14.28, NA 0.07, DOF 286um, Opt.Dist. 0.03

 Compare
SKU: 01077 Category:

Product Description

The Object Side Telecentric Lens TCST-20-40 is suitable for sensors with an image format of 1/2 inch.

Magnification2
MountC-Mount
Aperture14.28
Working Distance (WD)40 mm
Depth of Field (DOF)286 μm
Resolution (Object Side)4.8 μm
Numerical Aperture (NA)0.07
Image Format (max.)1/2 inch
Field of View (FOV)3.2mm x 2.4mm@1/2″ CCD
Lens TypeObject Side
Telecentricity0.03
Optical Distortion (max.)0.03 %
Special FeatureStandard
pdf

Additional Information

Technical Drawing:

Drawing
