Lensagon TCST-15-40

Lensagon TCST-15-40

Standard Object Side Telecentric Lens for 1/2 inch sensor, Magnification: 1.5x, WD 40mm, F# 11.9, NA 0.063, DOF 423um, Opt.Dist. 0.05

 Compare
SKU: 10200 Category:

Product Description

The Object Side Telecentric Lens TCST-15-40 is suitable for sensors with an image format of 1/2 inch.

Magnification1.5 x
Working Distance (WD)40 mm
Depth of Field (DOF)423 μm
Resolution (Object Side)5.32 μm
Image Format (max.)1/2 inch
Working F-Number11.9
Numerical Aperture (NA)0.063
Field of View (FOV)4.26mm x 3.2mm @ 1/2″
Telecentric TypeObject Side
Telecentricity0.03 °
Optical Distortion (max.)0.05 %
MountC-Mount *

* Other mounts are available on request.

pdf

Additional Information


Drawing
