Lensagon TCST-10-250-S118C
Standard Object Side Telecentric Lens for 1/1.8 inch sensor, Magnification: 1x, WD 250mm, F# 11, NA 0.045, DOF 484um, Opt.Dist. 0.081, Coaxial Version
Product Description
The Object Side Telecentric Lens TCST-10-250-S118C is suitable for sensors with an image format of 1/1.8 inch.
| Magnification | 1 x |
|---|---|
| Mount | C-Mount * |
| Working F-Number | 11 |
| Working Distance (WD) | 250 mm |
| Depth of Field (DOF) | 484 μm |
| Resolution (Object Side) | 7.45 μm |
| Numerical Aperture (NA) | 0.045 |
| Image Format (max.) | 1/1.8 inch |
| Field of View (FOV) | 6.78mm x 5.25mm @1/1.8″ CCD |
| Telecentric Type | Object Side |
| Telecentricity | 0.03 ° |
| Optical Distortion (max.) | 0.081 % |
| Special Feature | Standard |
* Other mounts are available on request.
