Lensagon TCST-05-40

Standard Object Side Telecentric Lens for 1/2 inch sensor, Magnification: 0.5x, WD 43mm, F# 8.3, NA 0.03, DOF 2600um, Opt.Dist. 0.02

 Compare
SKU: 10431 Category:

Product Description

The Object Side Telecentric Lens TCST-05-40 is suitable for sensors with an image format of 1/2 inch.

Magnification 0.50 x
Working Distance (WD) 43.00 mm
Depth of Field (DOF) 2.6 mm @ 40.00 μm
Resolution (Object Side) 11.20 μm
Image Format (max.) 1/2 inch
Working F-Number 8.30
Numerical Aperture (NA) 0.03
Field of View (FOV) 12.8mm x 9.6mm @ 1/2″
Telecentric Type Object Side
Telecentricity 0.03 °
Optical Distortion (max.) 0.02 %
Mount C-Mount *

* Other mounts are available on request.

pdf

Additional Information


Drawing
