Lensagon TCHR-035-130I
High Res Object Side Telecentric Lens for 1/2 inch sensor, Magnification: 0.35x, WD 130mm, F# 7.3, NA 0.0238, DOF 4.8um, Opt.Dist. 0.08
Product Description
The Object Side Telecentric Lens TCHR-035-130I is suitable for sensors with an image format of 1/2 inch.
| Magnification | 0.35 x |
|---|---|
| Working Distance (WD) | 130 mm |
| Depth of Field (DOF) | 4.8 μm @ 40 μm |
| Resolution (Object Side) | 14.1 μm |
| Image Format (max.) | 1/2 inch |
| Working F-Number | 7.3 |
| Numerical Aperture (NA) | 0.0238 |
| Field of View (FOV) | 18.3mm x 13.7mm @ 1/2″ |
| Telecentric Type | Object Side |
| Telecentricity | 0.035 ° |
| Optical Distortion (max.) | 0.08 % |
| Mount | C-Mount * |
* Other mounts are available on request.
