Lensagon TC5M-20-110I

High Res Object Side Telecentric Lens for 2/3 inch sensor, Magnification: 2x, WD 110mm, F# 11, NA 0.09, DOF 110um, Opt.Dist. 0.03

 Compare
SKU: 01069 Category:

Product Description

The Object Side Telecentric Lens TC5M-20-110I is suitable for sensors up to 5 megapixel and with an image format of 2/3 inch.

Magnification 2 x
Working Distance (WD) 110 mm
Depth of Field (DOF) 110 μm @ 20 μm
Resolution (Object Side) 3.7 μm
Image Format (max.) 2/3 inch
Megapixel (max.) 5 MP
Working F-Number 11
Numerical Aperture (NA) 0.09
Field of View (FOV) 4.2mm x 3.5mm @ 2/3
Telecentric Type Object Side
Telecentricity 0.05 °
Optical Distortion (max.) 0.03 %
Mount C-Mount *

* Other mounts are available on request.

pdf

Additional Information


Drawing
