Lensagon TC5M-05-65C
Super High Res Object Side Telecentric Lens for 2/3 inch sensor, Magnification: 0.5x, WD 65mm, F# 6.25, NA 0.04, DOF 690um, Opt.Dist. 0.03, Coaxial Version
Product Description
The Object Side Telecentric Lens TC5M-05-65C is suitable for sensors up to 5 megapixel and with an image format of 2/3 inch.
| Magnification | 0.50 x |
| Working Distance (WD) | 65 mm |
| Depth of Field (DOF) | 690 μm @ 20 μm |
| Resolution (Object Side) | 8.40 μm |
| Image Format (max.) | 2/3 inch |
| Megapixel (max.) | 5 MP |
| Working F-Number | 6.25 |
| Numerical Aperture (NA) | 0.04 |
| Field of View (FOV) | 17.6mm x 13.2mm @ 2/3″ |
| Telecentric Type | Object Side |
| Telecentricity | 0.02 ° |
| Optical Distortion (max.) | 0.03 % |
| Mount | C-Mount * |
* Other mounts are available on request.
