Lensagon T47M-13-105C

Super High Res Object Side Telecentric Lens for 56.7mm (diagonal) sensor, Magnification: 1.3x, WD 105mm, F# 10, NA 0.05, DOF 440um, Opt.Dist. 0.02, Coaxial Version

 Compare
SKU: 11006 Category:

Product Description

The Object Side Telecentric Lens T47M-13-105C is suitable for sensors up to 47 megapixel and with an image format of 56.7mm (diagonal).

Magnification1.3
MountM72
Aperture10
Working Distance (WD)105 mm
Depth of Field (DOF)440 μm
Resolution (Object Side)6.7 μm
Numerical Aperture (NA)0.05
Image Format (max.)56.7mm (diagonal)
Megapixel47
Field of View (FOV)37.46mm x 22.3mm
Lens TypeObject Side
Telecentricity0.04
Optical Distortion (max.)0.02 %
Special FeatureSuper High Res
pdf

Additional Information

Technical Drawing:

Drawing
