Lensagon CMFA3519ND

Lensagon CMFA3519ND

1 Megapixel C-Mount lens for 2/3 inch sensors, F1.9, f=35mm

 Compare
SKU: 00034 Category:

Product Description

The C-Mount lens Lensagon CMFA3519ND is suitable for common sensors up to 1 megapixel with an image format of 2/3 inch. It is characterized by a particularly high light intensity.

Mount C-Mount
Sensor 2/3 inch
Focal Length 35 mm
Aperture (f#) 1.9
MOD 0.3 m
max. WD 1
Angle of View (D) 17.86°
Megapixel (max.) 1 MP
IR Correction No
IR Cut Filter No
TV Distortion -0.03
Image Circle 11 mm
Weight 55 g
Iris manual-lock
Focus manual-lock
Filter M27 P=0.5
Typ Standard
pdf

Additional Information

Technical Drawing:

Drawing
