Product Description
The S-Mount lens Lensagon BE5M3625S125 is suitable for common sensors up to 5 megapixel with an image format of 1/2.5 inch.
| Mount | S-Mount |
|---|---|
| Sensor | 1/2.5 inch |
| Focal Length | 3.6 mm |
| Aperture (f#) | 2.5 |
| MOD | 0.2 m |
| Back Focal Length | 6.63 |
| Angle of View (D) | 126° / H: 92° / V: 68° |
| Megapixel (max.) | 5 MP |
| IR Correction | Yes |
| Optical Distortion | -49 % |
| Iris | fixed |
| Focus | fixed |
| Chief ray angle | 13.6 ° |
| Typ | Standard |
