Lensagon B6M6156S12C
6.0 Megapixel S-Mount lens for 1/2 inch sensors, F5.60, f=6.10mm, MOD 0.100m
Product Description
The S-Mount lens Lensagon B6M6156S12C is suitable for current sensors up to 6.0 megapixel with an image format of 1/2 inch.
| Mount | S-Mount |
| Sensor | 1/2 inch |
| Focal Length | 6.10 mm |
| Aperture (f#) | 5.60 |
| MOD | 0.100 m |
| Angle of View (D) | 65.30° / H: 54.30° / V: 41.90° |
| Megapixel (max.) | 6.0 MP |
| IR Cut Filter | Yes |
| Optical Distortion | -1 % |
| Image Circle | 8 mm |
| Weight | 4.67 g |
| Iris | fixed |
| Focus | fixed |
| Chief ray angle | 18.32 ° |
