Product Description
The S-Mount lens Lensagon B6M3422S12C is suitable for current sensors up to 6.00 megapixel with an image format of 1/1.8 inch.
| Mount | S-Mount |
| Sensor | 1/1.8 inch |
| Focal Length | 3.47 mm |
| Aperture (f#) | 2.20 |
| Back Focal Length | 4.44 |
| Angle of View (D) | 157.50° / H: 133° / V: 72° |
| Megapixel (max.) | 6 MP |
| IR Cut Filter | Yes |
| TV Distortion | -75 |
| Image Circle | 9.50 mm |
| Iris | fixed |
| Chief ray angle | 19.10 ° |
| Typ | Standard |
