Product Description
The S-Mount lens Lensagon B10M3218S123C is suitable for current sensors up to 10.00 megapixel with an image format of 1/2.3 inch. It is characterized by a particularly high light intensity.
| Mount | S-Mount |
|---|---|
| Sensor | 1/2.3 inch |
| Focal Length | 3.20 mm |
| Aperture (f#) | 1.80 |
| Back Focal Length | 5.91 |
| Angle of View (D) | 152.00° / H: 117.00° / V: 86.00° |
| Megapixel (max.) | 10.00 MP |
| IR Cut Filter | Yes |
| Image Circle | 8.20 mm |
| Chief ray angle | 17.20 ° |
| Filter | 640nm |
| Typ | Standard |
