Lensagon TDC4M-01-470I
High Res Double Side Telecentric Lens for 1.2 inch sensor, Magnification: 0.1x, WD 470mm, F# 7.7, NA 0.0065, DOF 61600um, Opt.Dist. 0.026
Product Description
The Double Side Telecentric Lens TDC4M-01-470I is suitable for sensors up to 4 megapixel and with an image format of 1.2 inch.
| Magnification | 0.10 x |
|---|---|
| Working Distance (WD) | 470.00 mm |
| Depth of Field (DOF) | 61.6 mm @ 22.00 μm |
| Resolution (Object Side) | 51.60 μm |
| Image Format (max.) | 1.2 inch |
| Megapixel (max.) | 4.00 MP |
| Working F-Number | 7.70 |
| Numerical Aperture (NA) | 0.0065 |
| Field of View (FOV) | 112.6mm x 112.6mm |
| Telecentric Type | Double Side |
| Telecentricity | 0.05 ° |
| Optical Distortion (max.) | 0.026 % |
| Mount | F-Mount * |
* Other mounts are available on request.
