Lensagon TCST-20-110

Lensagon TCST-20-110

Standard Object Side Telecentric Lens for 1/2 inch sensor, Magnification: 2x, WD 110mm, F# 22.2, NA 0.045, DOF 444um, Opt.Dist. 0.02

 Compare
SKU: 10310 Category:

Product Description

The Object Side Telecentric Lens TCST-20-110 is suitable for sensors with an image format of 1/2 inch.

Magnification2 x
Working Distance (WD)110 mm
Depth of Field (DOF)444 μm
Resolution (Object Side)7.5 μm
Image Format (max.)1/2 inch
Working F-Number22.2
Numerical Aperture (NA)0.045
Field of View (FOV)3.2mm x 2.4mm @ 1/2
Telecentric TypeObject Side
Telecentricity0.02 °
Optical Distortion (max.)0.02 %
MountC-Mount *

* Other mounts are available on request.

pdf

Additional Information


Drawing
