Lensagon TCST-10-65C
Standard Object Side Telecentric Lens for 1/2 inch sensor, Magnification: 1x, WD 65mm, F# 18.5, NA 0.027, DOF 1480um, Opt.Dist. 0.03, Coaxial Version
Product Description
The Object Side Telecentric Lens TCST-10-65C is suitable for sensors with an image format of 1/2 inch.
| Magnification | 1 x |
| Working Distance (WD) | 65 mm |
| Depth of Field (DOF) | 1.48 mm @ 40 μm |
| Resolution (Object Side) | 12.40 μm |
| Image Format (max.) | 1/2 inch |
| Working F-Number | 18.50 |
| Numerical Aperture (NA) | 0.027 |
| Field of View (FOV) | 6.4mm x 4.8mm @ 1/2″ |
| Telecentric Type | Object Side |
| Telecentricity | 0.02 ° |
| Optical Distortion (max.) | 0.03 % |
| Mount | C-Mount * |
* Other mounts are available on request.
