Lensagon TCST-10-40

Standard Object Side Telecentric Lens for 1/2 inch sensor, Magnification: 1x, WD 40mm, F# 9.26, NA 0.054, DOF 740um, Opt.Dist. 0.08

 Compare
SKU: 00822 Category:

Product Description

The Object Side Telecentric Lens TCST-10-40 is suitable for sensors with an image format of 1/2 inch.

Magnification 1.00 x
Working Distance (WD) 40.00 mm
Depth of Field (DOF) 740.00 μm @ 40.00 μm
Resolution (Object Side) 6.20 μm
Image Format (max.) 1/2 inch
Working F-Number 9.26
Numerical Aperture (NA) 0.054
Field of View (FOV) 6.4mm x 4.8mm @ 1/2″
Telecentric Type Object Side
Telecentricity 0.03 °
Optical Distortion (max.) 0.08 %
Mount C-Mount *

* Other mounts are available on request.

pdf

Additional Information


Drawing
