Lensagon TCST-08-110
Standard Object Side Telecentric Lens for 1/2 inch sensor, Magnification: 0.8x, WD 110mm, F# 14.8, NA 0.027, DOF 1850um, Opt.Dist. 0.05
Product Description
The Object Side Telecentric Lens TCST-08-110 is suitable for sensors with an image format of 1/2 inch.
| Magnification | 0.80 x |
| Working Distance (WD) | 110 mm |
| Depth of Field (DOF) | 1.85 mm @ 40 μm |
| Resolution (Object Side) | 12.40 μm |
| Image Format (max.) | 1/2 inch |
| Working F-Number | 14.80 |
| Numerical Aperture (NA) | 0.027 |
| Field of View (FOV) | 8mm x 6mm @ 1/2″ |
| Telecentric Type | Object Side |
| Telecentricity | 0.05 ° |
| Optical Distortion (max.) | 0.05 % |
| Mount | C-Mount * |
* Other mounts are available on request.
