Lensagon TC5M-10-110
Super High Res Object Side Telecentric Lens for 2/3 inch sensor, Magnification: 1x, WD 110mm, F# 6.5, NA 0.077, DOF 260um, Opt.Dist. 0.01
Product Description
The Object Side Telecentric Lens TC5M-10-110 is suitable for sensors up to 5 megapixel and with an image format of 2/3 inch.
| Magnification | 1 x |
|---|---|
| Mount | C-Mount * |
| Working F-Number | 6.5 |
| Working Distance (WD) | 110 mm |
| Depth of Field (DOF) | 260 μm |
| Resolution (Object Side) | 4.36 μm |
| Numerical Aperture (NA) | 0.077 |
| Image Format (max.) | 2/3 inch |
| Megapixel (max.) | 5 MP |
| Field of View (FOV) | 8.47mm x 7.1mm@5M CCD |
| Telecentric Type | Object Side |
| Telecentricity | 0.025 ° |
| Optical Distortion (max.) | 0.01 % |
| Special Feature | Super High Res |
* Other mounts are available on request.
