Lensagon TC5M-08-65C
Super High Res Object Side Telecentric Lens for 2/3 inch sensor, Magnification: 0.8x, WD 65mm, F# 6.25, NA 0.064, DOF 390.6um, Opt.Dist. 0.13, Coaxial Version
Product Description
The Object Side Telecentric Lens TC5M-08-65C is suitable for sensors up to 5 megapixel and with an image format of 2/3 inch.
| Magnification | 0.80 x |
|---|---|
| Mount | C-Mount * |
| Working F-Number | 6.25 |
| Working Distance (WD) | 65.00 mm |
| Depth of Field (DOF) | 390.60 μm |
| Resolution (Object Side) | 5.25 μm |
| Numerical Aperture (NA) | 0.064 |
| Image Format (max.) | 2/3 inch |
| Megapixel (max.) | 5.00 MP |
| Field of View (FOV) | 10.65mm x 8.87mm @5M CCD |
| Telecentric Type | Object Side |
| Telecentricity | 0.02 ° |
| Optical Distortion (max.) | 0.13 % |
| Special Feature | Super High Res |
* Other mounts are available on request.
