Lensagon TC5M-07-110

Lensagon TC5M-07-110

High Res Object Side Telecentric Lens for 2/3 inch sensor, Magnification: 0.7x, WD 110mm, F# 5.38, NA 0.0651, DOF 439um, Opt.Dist. 0.02

SKU: 10224 Category:

Product Description

The Object Side Telecentric Lens TC5M-07-110 is suitable for sensors up to 5 megapixel and with an image format of 2/3 inch.

Magnification0.7 x
Working Distance (WD)110 mm
Depth of Field (DOF)439 μm
Resolution (Object Side)5.15 μm
Image Format (max.)2/3 inch
Megapixel (max.)5 MP
Working F-Number5.38
Numerical Aperture (NA)0.0651
Field of View (FOV)12.1mm x 10.1mm @ 2/3
Telecentric TypeObject Side
Telecentricity0.02 °
Optical Distortion (max.)0.02 %
MountC-Mount *

* Other mounts are available on request.
