Lensagon TC4M-22-50C

High Res Object Side Telecentric Lens for 1 inch sensor, Magnification: 2.2x, WD 50mm, F# 8.14, NA 0.135, DOF 74um, Opt.Dist. 0.03, Coaxial Version

SKU: 11064 Category:

Product Description

The Object Side Telecentric Lens TC4M-22-50C is suitable for sensors up to 4 megapixel and with an image format of 1 inch.

Magnification 2.2 x
Working Distance (WD) 50 mm
Depth of Field (DOF) 74 μm @ 22 μm
Resolution (Object Side) 2.5 μm
Image Format (max.) 1 inch
Megapixel (max.) 4 MP
Working F-Number 8.14
Numerical Aperture (NA) 0.135
Field of View (FOV) 5.12mm x 5.12mm
Telecentric Type Object Side
Telecentricity 0.01 °
Optical Distortion (max.) 0.03 %
Mount C-Mount *

* Other mounts are available on request.
