Lensagon TC4M-05-65
Standard Object Side Telecentric Lens for 1 inch sensor, Magnification: 0.5x, WD 65mm, F# 8, NA 0.031, DOF 1400um, Opt.Dist. 0.03
Product Description
The Object Side Telecentric Lens TC4M-05-65 is suitable for sensors up to 4 megapixel and with an image format of 1 inch.
| Magnification | 0.5 x |
|---|---|
| Working Distance (WD) | 65 mm |
| Depth of Field (DOF) | 1.4 mm @ 22 μm |
| Resolution (Object Side) | 10.7 μm |
| Image Format (max.) | 1 inch |
| Megapixel (max.) | 4 MP |
| Working F-Number | 8 |
| Numerical Aperture (NA) | 0.031 |
| Field of View (FOV) | 22.53mm x 22.53mm |
| Telecentric Type | Object Side |
| Telecentricity | 0.04 ° |
| Optical Distortion (max.) | 0.03 % |
| Mount | C-Mount * |
* Other mounts are available on request.
