Lensagon CY3519

Lensagon CY3519

0.4 Megapixel C-Mount lens for 2/3 inch sensors, F1.9, f=35mm

 Compare
SKU: 00182 Category:

Product Description

The C-Mount lens Lensagon CY3519 is suitable for sensors below 1 megapixel with an image format of 2/3 inch. It is characterized by a particularly high light intensity.

Mount C-Mount
Sensor 2/3 inch
Focal Length 35 mm
Aperture (f#) 1.9
MOD 0.5 m
Back Focal Length 12.37
Angle of View (D) 17.86°
Megapixel 0.4 MP
IR Cut Filter No
TV Distortion 0.04
Image Circle 11 mm
Weight 49 g
Iris manual-lock
Focus manual-lock
Filter Size M27 P=0.5
Typ Standard
pdf

Additional Information

Technical Drawing:

Drawing
