Product Description
The C-Mount lens Lensagon CH12M0824S117 is suitable for current sensors up to 12.00 megapixel with an image format of 1/1.7 inch.
| Mount | C-Mount |
|---|---|
| Sensor | 1/1.7 inch |
| Focal Length | 8.00 mm |
| Aperture (f#) | 2.40 |
| MOD | 0.10 m |
| Back Focal Length | 17.53 |
| Angle of View (D) | 60.23° / H: 49.65° / V: 38.58° |
| Megapixel (max.) | 12.00 MP |
| TV Distortion | -1.43 |
| Typ | Standard |
