Lensagon BF12M1720S116C
12.00 Megapixel Fisheye S-Mount lens for 1/1.6 inch sensors, F2.00, f=1.70mm
Product Description
The S-Mount lens Lensagon BF12M1720S116C is suitable for current sensors up to 12.00 megapixel with an image format of 1/1.6 inch. It is characterized by a particularly high light intensity.
| Mount | S-Mount |
|---|---|
| Sensor | 1/1.6 inch |
| Focal Length | 1.70 mm |
| Aperture (f#) | 2.00 |
| MOD | 0.10 m |
| Back Focal Length | 4.30 |
| Angle of View (D) | 185.00° / H: 185.00° / V: 185.00° |
| Megapixel (max.) | 12.00 MP |
| IR Cut Filter | Yes |
| F-Theta Distortion | 27.40 |
| Image Circle | 7.07 mm |
| Iris | fixed |
| Chief ray angle | 11.00 ° |
| Filter | IR-CUT |
| Typ | Fisheye |
