Lensagon B5M12028-T
5.0 Megapixel S-Mount lens for 1/1.8 inch sensors, F2.80, f=12.00mm, MOD 0.100m
Product Description
The S-Mount lens Lensagon B5M12028-T is suitable for common sensors up to 5.0 megapixel with an image format of 1/1.8 inch.
| Mount | S-Mount |
| Sensor | 1/1.8 inch |
| Focal Length | 12 mm |
| Aperture (f#) | 2.80 |
| MOD | 0.100 m |
| Back Focal Length | 8.57 |
| Angle of View (D) | 41° / H: 34.30° / V: 23.20° |
| Megapixel (max.) | 5.0 MP |
| IR Correction | No |
| IR Cut Filter | No |
| Optical Distortion | -1.75 % |
| Iris | fixed |
| Focus | fixed |
