Lensagon TCST-60-40
Standard Object Side Telecentric Lens for 1/2 inch sensor, Magnification: 6x, WD 40mm, F# 37.4, NA 0.08, DOF 83um, Opt.Dist. 0.02
Product Description
The Object Side Telecentric Lens TCST-60-40 is suitable for sensors with an image format of 1/2 inch.
| Magnification | 6.00 x |
|---|---|
| Working Distance (WD) | 40.00 mm |
| Depth of Field (DOF) | 83.00 μm @ 40.00 μm |
| Resolution (Object Side) | 4.20 μm |
| Image Format (max.) | 1/2 inch |
| Working F-Number | 37.40 |
| Numerical Aperture (NA) | 0.08 |
| Field of View (FOV) | 1.06mm x 0.8mm @ 1/2 |
| Telecentric Type | Object Side |
| Telecentricity | 0.02 ° |
| Optical Distortion (max.) | 0.02 % |
| Mount | C-Mount * |
* Other mounts are available on request.
