Lensagon TCST-20-65

Standard Object Side Telecentric Lens for 1/2 inch sensor, Magnification: 2x, WD 65mm, F# 15.4, NA 0.065, DOF 308um, Opt.Dist. 0.03

 Compare
SKU: 09980 Category:

Product Description

The Object Side Telecentric Lens TCST-20-65 is suitable for sensors with an image format of 1/2 inch.

Magnification 2 x
Working Distance (WD) 65 mm
Depth of Field (DOF) 308 μm @ 40 μm
Resolution (Object Side) 5.2 μm
Image Format (max.) 1/2 inch
Working F-Number 15.4
Numerical Aperture (NA) 0.065
Field of View (FOV) 3.2mm x 2.4mm @ 1/2″
Telecentric Type Object Side
Telecentricity 0.02 °
Optical Distortion (max.) 0.03 %
Mount C-Mount *

* Other mounts are available on request.
