Lensagon TCST-10-220

Lensagon TCST-10-220

Standard Object Side Telecentric Lens for 2/3 inch sensor, Magnification: 1x, WD 220mm, F# 11, NA 0.045, DOF 880um, Opt.Dist. 0.01

 Compare
SKU: 10006 Category:

Product Description

The Object Side Telecentric Lens TCST-10-220 is suitable for sensors with an image format of 2/3 inch.

Magnification1
MountC-Mount
Working F-Number11
Working Distance (WD)220 mm
Depth of Field (DOF)880 μm
Resolution (Object Side)7.4 μm
Numerical Aperture (NA)0.045
Image Format (max.)2/3 inch
Field of View (FOV)8.8mm x 6.6mm@2/3″ CCD
Lens TypeObject Side
Telecentricity0.03
Optical Distortion (max.)0.01 %
Special FeatureStandard
pdf

Additional Information

Technical Drawing:

Drawing
