Lensagon TC5M-10-65

Super High Res Object Side Telecentric Lens for 2/3 inch sensor, Magnification: 1x, WD 65mm, F# 7.14, NA 0.07, DOF 285.6um, Opt.Dist. 0.16

 Compare
SKU: 00659 Category:

Product Description

The Object Side Telecentric Lens TC5M-10-65 is suitable for sensors up to 5 megapixel and with an image format of 2/3 inch.

Magnification 1.00 x
Working Distance (WD) 65.00 mm
Depth of Field (DOF) 285.60 μm @ 20.00 μm
Resolution (Object Side) 4.80 μm
Image Format (max.) 2/3 inch
Megapixel (max.) 5.00 MP
Working F-Number 7.14
Numerical Aperture (NA) 0.07
Field of View (FOV) 8.47mm x 7.1 mm @ 2/3″
Telecentric Type Object Side
Telecentricity 0.022 °
Optical Distortion (max.) 0.16 %
Mount C-Mount *

* Other mounts are available on request.
