Lensagon C10M1618S23
10.0 Megapixel C-Mount lens for 2/3 inch sensors, F1.80, f=16.00mm, MOD 0.150m
Product Description
The C-Mount lens Lensagon C10M1618S23 is suitable for current sensors up to 10.0 megapixel with an image format of 2/3 inch. It is characterized by a particularly high light intensity.
| Mount | C-Mount |
| Sensor | 2/3 inch |
| Focal Length | 16 mm |
| Aperture (f#) | 1.80 |
| MOD | 0.150 m |
| Back Focal Length | 11.75 |
| Angle of View (D) | 31.81° / H: 30.65° / V: 23.23° |
| Megapixel (max.) | 10.0 MP |
| Optical Distortion | -0.18 % |
| TV Distortion | 0.01 |
| Image Circle | 11 mm |
| Weight | 146 g |
| Iris | manual-lock |
| Focus | manual-lock |
