Product Description
The S-Mount lens Lensagon B8M4028S118NDC is suitable for current sensors up to 8 megapixel with an image format of 1/1.8 inch.
| Mount | S-Mount |
|---|---|
| Sensor | 1/1.8 inch |
| Focal Length | 4 mm |
| Aperture (f#) | 2.8 |
| MOD | 0.25 m |
| Back Focal Length | 5.7 |
| Angle of View (D) | 92.4° / H: 74.5° / V: 54° |
| Megapixel (max.) | 8 MP |
| IR Cut Filter | Yes |
| Optical Distortion | -3 % |
| Weight | 16 g |
| Iris | fixed |
| Focus | fixed |
| Chief ray angle | 21 ° |
| Typ | Standard |
